Dump Semi Trailer (自卸半挂车)
Dump semi trailer — rear tip, 30–60 ton, hydraulic lift, 4–6mm steel body.
Share with friends
Contact Us
Rear-tip dump semi trailer (自卸半挂车) manufactured by Shandong Shuyue Vehicle. Hydraulic front lift cylinder for fast discharge of sand, gravel, aggregates, and mining materials. Reinforced steel body for heavy-duty use.
Technical Specifications
| Parameter | Specification |
|---|---|
| Overall Dimension (mm) | 10500 × 2500 × 3500 (customizable) |
| Volume Capacity | 30 m³ / 40 m³ / 50 m³ / 60 m³ |
| Loading Capacity | 40T, 50T, 60T, 70T, 80T |
| Tipping Type | Rear tip (front lift cylinder, HYVA brand) |
| Lifting Cylinder | HYVA 220# / 196# hydraulic cylinder |
| Body Material | Q345B high-strength steel, 6mm side + 8mm floor |
| Main Beam | Q345B steel, height 500mm, plate 8-16mm |
| Axle | 13T / 16T / 20T BPW or FUWA, 3 / 4 axles |
| Tire | 11.00R20 / 12R22.5, 12 pieces |
| Rim | 8.25-22.5 / 9.00-22.5 |
| Suspension | Mechanical / Air suspension (lift axle optional) |
| Leaf Spring | 10 layers (90mm × 13mm × 10pcs) |
| King Pin | 50# or 90# JOST |
| Landing Gear | 28T JOST |
| Brake System | Dual-line air brake, WABCO |
| Brake Chamber | 6 sets, T30/30 |
| Tail Gate | Air-operated tail gate release |
| Tool Box | 1 standard steel toolbox |
| Painting | Sand-blasting, primer + 2 finish coats |
Application: Sand, gravel, aggregates, mining ore, construction debris, coal. Rear-tip design with hydraulic cylinder for fast cycle times.
Why Choose Shandong Shuyue Vehicle?
- 20+ years of trailer manufacturing experience in Liangshan — China’s largest special vehicle industry cluster
- Direct factory pricing — FOB Qingdao / Lianyungang / Tianjin
- Custom specifications available (dimensions, axles, capacity, color)
- CE / ISO9001 / GCC certification ready
- OEM / ODM service for distributors and fleet operators
- Pre-shipment inspection by SGS / BV / customer-appointed third party
- Spare parts supply and after-sales service
Order Process
- Inquiry with specifications (dimensions, payload, axle count, material)
- Quotation with technical drawing within 12 hours
- 30% deposit by T/T
- Production (25–35 days depending on model and quantity)
- Pre-shipment inspection and balance payment
- Shipping via FCL / Bulk / Ro-Ro to your destination port
