Chemical Acid Tanker Trailer (Carbon Steel / Stainless Steel)
Chemical acid tanker. Carbon steel for concentrated H₂SO₄, SS316L for dilute. 20k–35k L.
Share with friends
Contact Us
Chemical acid tanker semi trailer manufactured by Shandong Shuyue Vehicle. Designed for sulfuric acid, hydrochloric acid, and other corrosive chemicals. Material selection depends on concentration: carbon steel for concentrated sulfuric acid (≥70%), stainless steel SS316L for dilute acid.
Technical Specifications
| Parameter | Specification |
|---|---|
| Overall Dimension (mm) | 11500 × 2500 × 2900 (customizable) |
| Tank Capacity | 20,000L / 25,000L / 30,000L / 35,000L |
| Compartments | 3 – 4 compartments |
| Tank Material — Concentrated H₂SO₄ | Carbon steel Q345B, 6mm shell |
| Tank Material — Dilute H₂SO₄ | Stainless steel SS316L, 6mm shell |
| Interior Lining (optional) | PE / PTFE / rubber lining for extra corrosion resistance |
| Manhole | 500mm anti-corrosion manhole |
| Discharge Valve | DN80 PTFE-lined valve (for SS) or carbon steel ball valve (for CS) |
| Bottom Valve | Pneumatic bottom valve, anti-corrosion |
| Pressure Relief | Vacuum relief valve + emergency vent |
| Anti-Surge Baffle | Polypropylene baffles every 2m |
| Axle | 13T / 16T BPW or FUWA, 3 axles |
| Tire | 11.00R20 / 12R22.5, 12 pieces |
| Rim | 8.25-22.5 / 9.00-22.5 |
| Suspension | Mechanical / Air suspension |
| King Pin | 50# or 90# JOST |
| Landing Gear | 28T JOST |
| Brake System | Dual-line air brake, WABCO |
| Compliance | GB/T 18564, ADR optional |
| Painting | Acid-resistant epoxy coating |
Application: Sulfuric acid (H₂SO₄ concentrated or dilute), hydrochloric acid (HCl), phosphoric acid, sodium hydroxide. Material guidance: CS for ≥70% H₂SO₄, SS316L for dilute acid and other corrosive liquids.
Why Choose Shandong Shuyue Vehicle?
- 20+ years of trailer manufacturing experience in Liangshan — China’s largest special vehicle industry cluster
- Direct factory pricing — FOB Qingdao / Lianyungang / Tianjin
- Custom specifications available (dimensions, axles, capacity, color)
- CE / ISO9001 / GCC certification ready
- OEM / ODM service for distributors and fleet operators
- Pre-shipment inspection by SGS / BV / customer-appointed third party
- Spare parts supply and after-sales service
Order Process
- Inquiry with specifications (dimensions, payload, axle count, material)
- Quotation with technical drawing within 12 hours
- 30% deposit by T/T
- Production (25–35 days depending on model and quantity)
- Pre-shipment inspection and balance payment
- Shipping via FCL / Bulk / Ro-Ro to your destination port
