Concrete Mixer Semi Trailer
Concrete mixer semi trailer — 8–14m³ drum, 3 axles, hydraulic drive.
Share with friends
Contact Us
Concrete mixer semi trailer (混凝土搅拌半挂车) manufactured by Shandong Shuyue Vehicle. Drum mixer for transporting ready-mix concrete to construction sites. Hydraulically driven via tractor PTO or auxiliary diesel engine.
Technical Specifications
| Parameter | Specification |
|---|---|
| Overall Dimension (mm) | 8500 × 2550 × 3800 (customizable) |
| Drum Capacity | 8 m³ / 10 m³ / 12 m³ / 14 m³ |
| Drum Material | Q345B high-strength steel, 6mm shell, 10mm helical blades (NM400 wear-resistant) |
| Drum Rotating Speed | 0 – 14 rpm |
| Drum Inclination | 12° |
| Charge Rate | ≥ 3 m³ / min |
| Discharge Rate | ≥ 2 m³ / min |
| Drive System | Hydraulic motor + gearbox, driven by tractor PTO |
| Water Tank | 400L – 600L |
| Main Beam | Q345B steel, height 500mm |
| Axle | 13T / 16T BPW or FUWA, 3 axles |
| Tire | 12R22.5, 12 pieces |
| Rim | 9.00-22.5 |
| Suspension | Mechanical / Air suspension |
| King Pin | 50# or 90# JOST |
| Landing Gear | 28T JOST |
| Brake System | Dual-line air brake, WABCO |
| Painting | Sand-blasting, primer + 2 finish coats |
Application: Ready-mix concrete transport from batching plant to construction site. Drum keeps concrete mixing during transit to prevent setting.
Why Choose Shandong Shuyue Vehicle?
- 20+ years of trailer manufacturing experience in Liangshan — China’s largest special vehicle industry cluster
- Direct factory pricing — FOB Qingdao / Lianyungang / Tianjin
- Custom specifications available (dimensions, axles, capacity, color)
- CE / ISO9001 / GCC certification ready
- OEM / ODM service for distributors and fleet operators
- Pre-shipment inspection by SGS / BV / customer-appointed third party
- Spare parts supply and after-sales service
Order Process
- Inquiry with specifications (dimensions, payload, axle count, material)
- Quotation with technical drawing within 12 hours
- 30% deposit by T/T
- Production (25–35 days depending on model and quantity)
- Pre-shipment inspection and balance payment
- Shipping via FCL / Bulk / Ro-Ro to your destination port
Contact
WhatsApp / Phone: +86 15376192345
Email: info@shuyue-trailer.com
Factory address: Liangshan Industrial Park, Jining City, Shandong Province, China
